eZ80F92 Development Kit
User Manual
40

Console

Modem

2
I C Devices
Device/Bit #
EEPROM (U10)*
Configuration Register (U13)
Note: *EEPROM address bits A0 and A1 are configured for 0s.
I2C Devices
Connector P2 is the RS232 terminal, which can be used for observing the
console output. P2 can be connected to the HyperTerminal if required.
Connector P3 provides a terminal for connecting an external modem, if
used with the eZ80F92 Development Kit. RS485 functionality will be
available in future eZ80
2
The two I C devices on the eZ80
EEPROM and the U13 Configuration register. The EEPROM provides
16KB of memory. The Configuration register provides access to control
the configuration of an application-specific function at the Application
Module Interface. Neither device is utilized by the eZ80F92 Development
Kit software. The user is free to develop proprietary software for these
two devices. The addresses for accessing these devices are listed in
Table 23.
Table 23. I
®
devices.
®
Development Platform are the U2
2
C Addresses
7 6 5 4
1 0 1 0
1 0 0 1
PRELIMINARY
3 2 1 0
0 A1 A0 R/W
1 1 0 R/W
UM013904-0203
