Table 3. Ez80 ® Development Platform I/O Connector Identification-Jp2 - ZiLOG eZ80F92 User Manual

Pin # Symbol
1 PB7
2 PB6
3 PB5
4 PB4
5 PB3
6 PB2
7 PB1
8 PB0
9 GND
10 PC7
11 PC6
12 PC5
13 PC4
14 PC3
15 PC2
16 PC1
17 PC0
18 PD7
Notes:
1. For the sake of simplicity in describing the interface, Power and Ground nets are omitted from
this table. The entire interface is represented in the eZ80F92 Module Schematics
through 64.
2. The Power and Ground nets are connected directly to the eZ80F92 device.
UM013904-0203
®
Table 3. eZ80 Development Platform
I/O Connector Identification—JP2*
Signal Direction
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
PRELIMINARY
eZ80F92 Development Kit
Active Level
Operational Description
User Manual
2
eZ80F92 Signal
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
on pages 62
17
