Axis 2N Access Unit Configuration Manual page 71

Touch Keypad & RFID Reader 125 kHz, 13.56 MHz
13.56 MHz (125 kHz) Card Reader (serial number)
Module Name – set the module name for card reader logging purposes.
Door – set the reader direction (Not specified, Arrival, Departure) for the
Attendance system purposes.
Associated Switch – set the switch to be activated after user authentication via
this module. If you set Door Lock Switch, the authentication rules specified in
Hardware / Door will be used.
Allowed Card Types – set the type of a card to be accepted by the card reader.
The card reader supports just one card type at an instant.
Forward to Wiegand Output – set a group of Wiegand outputs to which all the
received RFID card IDs will be resent.
