Axis 2N Analog Force Configuration Manual

Additional switch
Hide thumbs Also See for 2N Analog Force:

Advertisement

Quick Links

®
2N Analog Force
Additional Switch
Configuration Manual
Version:
1.1
www.2n.cz

Advertisement

loading

Summary of Contents for Axis 2N Analog Force

  • Page 1 ® 2N Analog Force Additional Switch Configuration Manual Version: www.2n.cz...
  • Page 2 The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of telecommunications equipment. The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years and represented a symbol of stability and prosperity on the telecommunications market for almost two decades.
  • Page 3: Table Of Contents

    Content: 1. Product Overview 2. Installation 3. Configuration 4. External button switch 5. Technical Parameters 2N TELEKOMUNIKACE a.s., www.2n.cz 3/12...
  • Page 4: Product Overview

    1. Product Overview ® The purpose of this module is to extend the Analog Force/Safety door communicator with another switch, e.g., for electric door lock. It gives you features like unlimited time switching or permanent switch during the time of the call or time limited switching (selectable approx.
  • Page 5: Installation

    2. Installation Caution Before installing the module, make sure that the current and voltage limits of the module will not be exceeded in your application (refer to the Technical Parameters chapter). Never use this module for mains voltage switching! All wiring has to be done only after proper installation of the additional switch.
  • Page 6 Remove 4 screws holding 2 horizontal pillars, then remove the pillars and button board. Replace 2 distance pillars from the lower side of intercom by the 2 longer distances delivered with departure switch. Insert departure switch and fix it with the two shorter distance pillars delivered with the switch.
  • Page 7 Put the horizontal pillars and button board back and fix them with 4 screws. Put the keypad back. Close the intercom with top metal plate and fix it with 4 screws. 2N TELEKOMUNIKACE a.s., www.2n.cz 7/12...
  • Page 8: Configuration

    3. Configuration By using jumpers it is possible to set on what kind of event should departure switch react by closing or opening its contacts. The departure switch can react to three different events: dep. switch on/off from the SWITCH 1, dep. switch on/off from the SWITCH 2 and pick up/hang up the telephone line (means beginning and end of the call).
  • Page 9 Example 2 – dep. switch operation for unlimited time Dep. switch closure is set to SWITCH 1, dep. switch opening to SWITCH 2. The dep. switch will close when it has received the password for SWITCH 1 and will remain closed until the communicator has received the password for SWITCH 2 and until the switching time of SWITCH 2 elapses (parameter , it is recommended to set this...
  • Page 10: External Button Switch

    4. External button switch External switch functional description After an external button ( switch on the pic. above) is pushed (switch OFF/ON), The "departure switch" occurs regardless of configuration settings . After an external button is released (switch ON/OFF) "departure switch" ends automaticaly after preset delay time by adjustable rotary trimmer from approx.
  • Page 11: Technical Parameters

    5. Technical Parameters Switching device: Latching relay Max. switching voltage: 60 V AC/DC Max. switching current: 2 A AC/DC Max. switching power: 60 VA / 30 W Power supply for external button input: voltage 10 15 (V), available current must be: 6 mA.
