INSTALLATION: CRUMB TRAY / SLIDING DECKS / REAR LEDGE & STORAGE / TONGS & BAG
8. Crumb Tray / Sliding Decks / Rear Ledge &
Storage / Tongs & Bag (Optional)
A. Sliding Decks: Decks slide side-to-side.
Collapsible
Rear Ledge
Crumb Tray
Storage
Slots (on
Each Deck)
Rear Ledge
Support Rod
Rear Ledge Brackets
Sliding
Removable
Decks
Crumb Tray
Slot
7
B. Crumb Tray Slots: Crumbs may be brushed into
open slots in decking (and down into removable
crumb tray).
C. Removable Crumb Tray: Simply remove crumb
tray from slot, empty and replace. See cleaning
schedule for specifics on cleaning.
D. Collapsible Rear Ledge: When not in use, lift up
and allow support rod to collapse. Lower ledge
downward. Reverse this procedure when rear
ledge is needed. See cleaning schedule for
specifics on cleaning. Note: Entire Rear Ledge
is able to be raised or lowered along bracket rail.
E. Tongs/Bags Retainer: Suction cups hold in place
on rear glass doors.
F. Storage is provided at lower section at rear of
case. See illustration below.
Collapsible
Removable
Rear Ledge
Crumb Tray
Tongs / Bags
Retainer
