2.
GENERAL
2.1.
General view
1:5
1:4
1:6
1:3
1:1
Legend:
1:1 Left-hand door
1:2 Right-hand door
1:3 Safety locks with keys
1:4 Arm bracket (BL52)
1:5 Arm bracket (BL53)
1:6 Hood
1:7 Housing
1:8 Fixing brackets
1:9 Stainless steel heater
1:10 Emergency crank hole
1:11 Emergency crank handle
1:12 Commercial identification plate
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other than the use of the products or the
execution of the project to which it refers, and from communicating it to third parties without Automatic Systems' prior written agreement. Document subject to change without notice.
BL5x-MT-EN-13
1:12
1:2
1:10
1:11
1:7
1:8
1:9
5/56
