Parameter
Log
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other than the use of the products or the execution of the project to which
it refers, and from communicating it to third parties without Automatic Systems' prior written agreement. Document subject to change without notice.
BL5x-MT-EN-13
Values Description
Display of the last 100 events (use ► the ▲ and keys to view
preceding events).
For the first two seconds, the event number (00 for the last
event recorded (= most recent), 01 for the preceding event, and
so on), as well as the date (year-month-day) and time (hours-
minutes-seconds) of creation are displayed.
In the next two seconds, the event description is displayed.
For example:
2 s
2 s
2 s
2 s
Note: If no error message is displayed when the machine fails,
refer to the Troubleshooting chapter.
Power Up Power was turned on.
Power Down Power was turned off.
Short Circuit Short circuit of the control board outputs (connector blocks). The
short circuit is declared and the equipment put Out of Service
only after 3 unsuccessful reactivation tries within the 2.5
seconds following a voltage drop in the 24V power supply (this
is to avoid putting it out of service at inopportune moments, as
for example during a network changeover to an emergency
generator).
If one of the outputs short circuits, all of them become inactive
and the control board must be powered up again for the outputs
to be reactivated.
Open Time Out Time out during opening: the time allocated for opening was
exceeded (TIMING menu, OpenTimeOut parameter).
Close Time Out Time out during closing: the time allocated for closing was
exceeded (TIMING menu, CloseTimeOut parameter).
Close Retries Allotted number of trials to close have been executed (as
defined in the TIMING menu).
Arm Swing Off Arm detected out of its support jaw (see the Arm Swing Off
parameter in the OPTIONS menu).
If the message continues to be displayed after the arm is
rehinged, check the status of the SW arm presence sensor and
its fastening.
Out Of Service Apparatus out of service. This may be caused by the following
events:
Log
00 060324 235034
Log
Out Of Service
Log
01 060324 235034
Log
Open Time Out
1) Time out during opening (see Open Time Out
message).
2) Time out during closing (see Close Time Out error) +
allotted number of tries to close have been executed
(see Close Retries message).
3) Arm is unhinged (see Arm Swing Off message).
4) Locking or unlocking failure of the BL4x (see Unlock
BL4x Er message).
5) Defect of the frequency inverter.
On 24 March 2006 at 23 hours
(11 p.m.) 50 minutes and 34
seconds...
...the apparatus was put out of
service.
View the preceding message
(01) using the ►▲ keys...
...we observe that it was put out
of service due to a time out
while opening.
