AS1320 Control board

(Extract from AS1320 technician manual)
5:1
5:2
5:3
5:7
5:4
5:1. Fuses
5:2. Stabilised power supply indicator light
5:3. Menu display screen
5:4. Menu navigation keys
5:5. RJ45 communication connector
5:6. In/Out control connector blocks
5:7. 5 green LEDs (lit when the board is on)
5:8. Connectors for presence detectors (for inductive loops)
