-- If the case occurs, mount the shrouds on the new arm referring to paragraph [4.5. Fixing the shrouds].
-- Make the necessary adjustments referring to paragraphs [4.7. Levelling the barrier arm], [5.1. Arm
balance adjustment] and [5.3. Safety torque limiter adjustment].
Notes: -- If you install an accessory on the barrier arm (road sign, traffic lights, etc.) or remove one, refer
to paragraphs [4.7.], [5.1.] and [5.3.] to re-adjust the arm balance.
-- Should the shaft be replaced, please contact your local Automatic Systems agent for further
information.
-- To replace the spring, follow the procedure described here above (same paragraph 5.5).
-- If the mains frequency is 60Hz, you may have to change the pulley/belt combination. If
necessary, contact your local Automatic Systems agent.
