BL52 (round arm)
Arm length (up to)
6,00m
6,50m
7,00m
7,50m
8,00m
8,50m
9,00m
9,50m
10,00m
10,50m
11,00m
11,50m
12,00m
12,50m
13,00m
13,50m
14,00m
BL53 (oval arm)
Arm length (up to)
4,00m
4,50m
5,00m
5,50m
6,00m
6,50m
7,00m
7,50m
8,00m
(Theoretical data for a standard basic arm tube, according to most common configurations).
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other than the use of the products or the
execution of the project to which it refers, and from communicating it to third parties without Automatic Systems' prior written agreement. Document subject to change without notice.
BL5x-MT-EN-13
Fixing points
b-1
b-1
b-1
b-1
b-1
b-1
b-1
b-3
c-1
c-1
c-2
c-2
d-3
d-3
d-1
d-2
e-4
Fixing points
b-3
b-2
c-3
c-3
c-2
d-1
d-1
e-3
f-3
f
e
d
c
b
a
1 2 3 4 5 6 7 8
Distance "x"
45mm
55mm
60mm
65mm
70mm
75mm
80mm
65mm
65mm
80mm
90mm
120mm
96mm
104mm
125mm
130mm
130mm
Distance "x"
60 mm
60 mm
45 mm
55 mm
160 mm
110 mm
130 mm
125 mm
130 mm
