Ier Automatic Systems BL52 Operating Manual page 2

Rev Date
02 Apr 05, 2007
03 July 19, 2007
04 13 nov. 07
05 June 09, 2008
06 July 3, 2008
07 2009-08-03
08 2009-08-20
09 2009-11-26
10 2010-01-04
11 2010-06-30
12 2010-11-04
13 2011-01-05
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other than the use of the products or the
execution of the project to which it refers, and from communicating it to third parties without Automatic Systems' prior written agreement. Document subject to change without notice.
BL5x-MT-EN-13
Revision page
Written by Checked by
MFy SD + JB
MFy
MFy
MFy
MFy
MFy
MFy
MFy
MFy
MFy
MFy
MFy
Nature of the modification
- Replacement of D1 control board by AS1320
(version 3.6 of the program) => ch 3 added.
- Update of the balance table (ch. 5.5).
- Update the emergency operation (ch 2.5.2).
- Adapt to software version 4.1 of AS1320 control
board (ch 3).
- Update of the balance table (ch 5.5).
- Addition of balance spring fixing bolt inspection (ch 6).
- Update of the conformity certificates (ch 9).
- Adition of the note regarding BLG76 (p1).
- Control board: adapted to version 6.x of the program.
- Revision of the electric diagram & addition of
connector blocks assignment.
Ch. 7.1: adapt the detection loops pinning references
to electric drawings (X9-X11-X13-X14).
Ch. 2.4: operation t° modification.
Ch. 9: EC certificate update.
Ch. "Safety warnings" & "Installing the arm": add
warning.
Ch.1: warning added regarding detection loops
installation.
Ch.3 adapted to control board v 6.2 (no functional
modification).
EC certificate update.
Electrical connections: add warning regarding
power network.
AS1320 menus: translation corrected by RW K.
Ch. 3.1: Download Chg Lvx parameters description
modified.
2/56
