Parameter
Path Cost
Designated Bridge
Top
Next / Prev
Refresh
The following illustration shows the IH Browser application provided with the
radios. Notice it shows the radio named Hematite_4F, linked to Amethyst_BD.
This link is shown with a red dotted line. Also visible is the level of redundancy in
their network. Each of the blue lines represents an alternate parent. From this
view, it is easily shown how much redundancy exists in their network.
To display the redundant paths, select the toolbar button denoting two "parents."
To view the redundancy on a per-radio basis, select the single Parent button,
and then click on the radio to view its available redundancies.
ProSoft Technology, Inc.
Description
The cumulative cost of all wired and wireless links from the port to the
Spanning Tree root.
The Next bridge toward the Spanning Tree root for this port.
Click the T button to see the top of the table.
OP
If the table has more ports than it can display in the window, use the
N and P buttons to move up and down through the table.
EXT REV
Click R to update the table.
EFRESH
