ProSoft Technology RLX2-IHx Series User Manual page 168

Using the IH Browser to Manage your Radios
User Manual
The Foreign AP Detection display columns
Column
MAC
SSID
Channel
RSSI
Detected By
First Detected
Last Detected
Is ProSoft
RLX2 Name
WL Added
Page 168 of 250
Description
MAC address of the AP,
The SSID that the AP is advertising in its Beacon,
The channel number on which the AP was detected,
The signal strength of the AP as measured by the detecting unit.
Note: if more than one 'Connected RLX2s' the same AP the table will
display the information from the unit that measured the highest RSSI.
The name and IP Address of the Connected RLX2 that detected the
AP with the strongest RSSI.
The date/time that the AP was first detected by any Connected RLX2.
Only the time is shown if the date is the same as the current date.
The elapsed time since information was last received for the AP. Can
occur if an AP is powered down or moved out of range.
Indicates 'Yes' if the AP is a ProSoft RLX2, 'No' otherwise.
The name of the unit if it is an RLX2. This column will only contain a
value in the 'Connected RLX2s' section.
The time that an AP was added to the whitelist.
RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
ProSoft Technology, Inc.
