ProSoft Technology RLX2-IHx Series User Manual page 211

RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
Class ID: 0xA2 (162) - RLX2 Info Extended
Number of Instances: 1
Available from RLX2 radios with firmware RLX2_v0038_R or later.
CIP Data Tag Name
RLX2_Diag.SSID
RLX2_Diag.IPAddress
RLX2_Diag.MACAddress
RLX2_Diag.NetworkMode
RLX2_Diag.ConnectionState
RLX2_Diag.SignalStrength
RLX2_Diag.Channel
RLX2_Diag.WEP
RLX2_Diag.Flags
RLX2_Diag.MasterMACAddress
RLX2_Diag.HopCount
RLX2_Diag.Status
RLX2_Diag.NumAssociations
RLX2_Diag.NumBridgeAssocs
RLX2_Diag.TxRadioThroughput
RLX2_Diag.TxRadioThroughput
RLX2_Diag.Uptime
RLX2_Diag.Linktime
RLX2_Diag.TxPktThput
RLX2_Diag.RxPktThput
RLX2_Diag.ModuleName
RLX2_Diag.ProductName
RLX2_Diag.ImageVerStr
RLX2_Diag.tx_good
RLX2_Diag.rx_good
RLX2_Diag.tx_bad
RLX2_Diag.rx_bad
RLX2_Diag.tx_directed_frames
RLX2_Diag.tx_multicast_frames
RLX2_Diag.tx_broadcast_frames
RLX2_Diag.rx_directed_frames
RLX2_Diag.rx_multicast_frames
RLX2_Diag.rx_broadcast_frames
RLX2_Diag.rx_crc_err
RLX2_Diag.Retries
RLX2_Diag.Utilization
RLX2_Diag.ChannelWidth
RLX2_Diag.NumAntennas
ProSoft Technology, Inc.
Appendix E - EtherNet/IP and Modbus TCP/IP Support
Data Type
SINT[32]
SINT[4]
SINT[6]
SINT
SINT
INT
SINT
SINT
DINT
SINT[6]
SINT
SINT
INT
INT
INT
INT
DINT
DINT
DINT
DINT
SINT[32]
SINT[32]
SINT[28]
DINT
DINT
DINT
DINT
DINT
DINT
DINT
DINT
DINT
DINT
DINT
SINT
SINT
SINT
SINT
User Manual
Access
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Page 211 of 250
