Network Planning
User Manual
2.1

Installing the ProSoft Wireless Designer

You can install the ProSoft Wireless Designer software to help you design your
RLX2-IHx series radio network. You can always get the newest version of
ProSoft Wireless Designer from the ProSoft Technology website
technology.com).
To install ProSoft Wireless Designer from the ProSoft Technology website
1 Open your web browser and navigate to www.prosoft-technology.com.
2 Use the search box on the ProSoft Technology page to search for ProSoft
Wireless Designer and then click the link for the ProSoft Wireless Designer.
3 Click the Downloads tab and then click ProSoft Wireless Designer to
download the latest version of the software.
4 Choose S
5 Save the file to your Windows Desktop, so that you can find it easily when
you have finished downloading.
6 When the download is complete, locate and double-click the zip file. This
extracts the installation file (Installer.msi).
7 Double-click the .msi file to install the software.
You can download sample programs, utilities, firmware images, and
documentation for your radio from the ProSoft Technology website
technology.com). If your computer does not have access to the Internet, you
must download the software from the ProSoft Technology website to removable
media, and then copy it to your computer.
2.2

Installation Questions

The following questions will help in getting familiar with the system.
How many radios are in the network?
Master ID:
Repeater ID:
Client ID:
Locations:
Is there a clear line of sight between them?
What type of antennas will be used in the
network?
Will you use the Personality Module configuration
restoration feature (MicroSD card)?
