4.2.3 Viewing the Radio Port Status

To view the Port Status Table, click P
This table shows all of the active ports on the radio. This window displays
information about the current S
S T
PANNING REE
Spanning Tree. Each RLX2-IHx series radio can have up to 34 active ports – one
Ethernet cable, one parent RF link, and up to 32 child RF links.
The primary reason for creating a Spanning Tree is that it allows you to create
fully redundant paths. If any single radio in a redundant path loses its connection,
and if another path still exists, the radio updates the connection to
communication restored.
Parameter
Spanning Tree Protocol:
Wireless Ports
Ethernet Port
Edge Port
Spanning Tree Root:
MAC
Priority
Max Age
Hello Time
Forward Delay
#
Connection
State
Designation
Page 64 of 250
PANNING
R device, and the timing parameters for the current
OOT
Description
The Spanning Tree Protocol level for the wireless port (Rapid STP or
STP).
The Spanning Tree Protocol level for the Ethernet port (Rapid STP or
STP).
Displays Active or Inactive based on the setting of Ethernet Edge Port in
the Spanning Tree configuration dialog.
The MAC ID of the root device in the spanning tree.
Spanning Tree device with the lowest-priority value is elected the root of
the tree
The length of time a port can stay enabled without any new spanning
updates.
The length of time between the transmission of spanning update packets.
The length of time a port must listen for spanning information before
being activated.
Position in the list. Each page shows up to 10 ports. Use the Next and
Previous buttons to move up and down through the table.
This parameter indicates what the port represents: Ethernet, a Parent
radio, or a Child radio.
The current Spanning Tree state of the port. Possible states are
Blocking, Learning, Listening, and Forwarding. Forwarding packets can
be transferred.
The Spanning Tree designation for the branch off the port. Possible
designations are Root (ports going to the root), Designated (ports going
to a branch), or Normal.
S .
ORT TATUS
T including the MAC address of the
REE
