NEX ROBOTICS FIREBIRD V ATMEGA 2560 Hardware Manual page 48

PIN Pin name
NO (ATMEGA8 slave uC)
14 (SS/OC1B) PB2
15 (MOSI/OC2) PB3
16 (MISO) PB4
17 PB5 (SCK)
19 ADC6
22 ADC7
28 PC5 (ADC5/SCL)
Table 3.14: Connections of the IR Proximity sensors with the ATMEGA8 (slave
* In System programming and Multi-processor communication between master and salve
microcontroller
MOSI, MISO, SCK and SS pins of ATMEGA2560 (master microcontroller) are connected to the
ISP (In System programming) port as well as the SPI bus of ATMEGA8 (slave microcontroller).
Hence to do ISP you need to disconnect jumper J4 on the microcontroller adaptor board. To
access data from the slave microcontroller ATMEGA8 over SPI bus Jumper J4 on the
microcontroller socket needs to be connected.
© NEX Robotics Pvt. Ltd. and ERTS Lab, CSE, IIT Bombay, INDIA
ISP (In System Programming) and SPI Communication with
ATMEGA2560. *
ADC input for IR proximity analog sensor 7
ADC input for IR proximity analog sensor 8
ADC input for IR proximity analog sensor 6
microcontroller)
Fire Bird V ATMEGA2560 Hardware Manual
USED FOR
48
