Distech Controls ECLYPSE Installation Manual page 6

Inter-Connection Gap: 0.01 [0.40]
0.51 [12.90]
4.74 [120.31]
5.30 [134.65]
0.06 [1.44]
Figure 9: ECY-MBUS Communication Module
See the ECLYPSE Selection Tool to determine the width of a specific assembly and the assembly order.
Status LED, DIP Switch, and Jumper Identification and Configuration
ECY-S1000
The Control, Automation and Connectivity Server has the following onsite configurable jumpers or DIP switches located inside the cover. Orient the cir-
cuit board as shown in the figure below.
HOST
SEC PRI
* Factory-default positions
Figure 10: ECY-S1000 Jumper, DIP Switch, and Reset Button Locations
6 / 22
3.20 [81.17]
L2- L2- L1+
M-Bus
POWER RX TX STATUS
MBUS
HOST
1x
Front
2.95 [74.99]
SUBNET
SUBNET EOL
Termination
EOL Off EOL On
(Disabled)* (Enabled)
RS-485 EOL Termination
Option Configuration
1
BIAS +
RESET
RS-485
2.31 [58.56]
Profile
HOST
2 3
ON
OFF*
EOL BIAS -
SEC
* Factory-default positions
Back
SUBNET
SUBNET EOL
Termination
EOL Off
(Disabled)*
RS-485 EOL
EOL Off
(Disabled)*
RESET
PRI RS-485
0.83 [21.08]
3.18 [80.82]
0.73 [18.54]
Inches [Millimeters]
EOL On
(Enabled)
Termination
EOL On
(Enabled)
