Distech Controls ECLYPSE Installation Manual page 5

4.74" 120.31
4.80" 121.75
0.06" 1.44
Figure 7: IO Module: Wide Width
Inter-Connection Gap: 0.01 [0.40]
0.51 [12.90]
4.74 [120.31]
5.30 [134.65]
0.06 [1.44]
Figure 8: RS-485 Communication Module
5.15" 130.07
Inter-Connection Gap: 0.01" 0.40
O1 O2 O3 O4 O5 O6 O7 O8
MAN
AUTO
OFF
Front
4.94" 125.32
3.20 [81.17]
RX1 TX1 RX2 TX2
Front
2.95 [74.99]
2.31" 58.56
2.31" 58.56
0.83
3.18" 80.82
0.73
Back
Inches Millimeters
0.83 [21.08]
3.18 [80.82]
0.73 [18.54]
Back
Inches [Millimeters]
5 / 22
21.08
18.54
