Distech Controls ECLYPSE Installation Manual page 4

0.44" 11.13
4.74" 120.31
5.24 133.03
0.06" 1.44
Figure 5: 100 to 240 VAC Power Supply
IO Modules come in the following widths.
Models
Narrow models: ECY-8UI,
ECY-8UI6UO, ECY-8UI6UO-HOA, ECY-8UI6DOT, and ECY-8UI6DOT-HOA
Wide models: ECY‑8DOR and ECY‑8DOR‑HOA.
Inter-Connection Gap: 0.01" 0.40
4.74" 120.31
4.80" 121.75
0.06" 1.44
Figure 6: IO Module: Narrow Width
4 / 22
4.08" 103.65
Inter-Connection Gap: 0.01" 0.40
Front
3.83" 97.33
ECY-16DI, ECY-6UO, ECY-6UO-HOA,
3.20" 81.17
Front
2.95" 74.99
2.31" 58.56
ECY-4UI4UO, ECY-4UI4UO-HOA,
2.31" 58.56
0.83 21.13
3.18" 80.82
0.72 18.39
Back
Inches Millimeters
Width
3.20 inches (81.17mm)
5.15 inches (130.07mm)
0.83
3.18" 80.82
0.73
Back
Inches Millimeters
21.08
18.54
