Distech Controls ECLYPSE Installation Manual page 3

Module Enclosure Dimensions
4.74" 120.31
5.13" 130.29
0.39" 9.98
0.06" 1.44
Figure 3: ECY-S1000 Module
0.40" 10.25
Inter-Connection Gap:
4.74" 120.31
5.20" 132.00
0.06" 1.44
Figure 4: 24V Power Supply
3.57" 90.67
Inter-Connection Gap: 0.01" 0.40
Front
3.33" 84.47
2.85" 72.38
0.01" 0.40
Front
2.61" 66.19
2.31" 58.56
2.31" 58.56
0.4" 1.09
0.83
3.18" 80.82
0.73
Back
Inches Millimeters
0.83 21.13
3.18" 80.82
0.72 18.39
Back
Inches Millimeters
3 / 22
21.08
18.54
