AIR LOGIC POWER SYSTEMS (ALPS)
Step Procedure Description
4. Replace C. Tighten the new timing screw in position. Verify that the keyway opening in the timing
timing screw
continued D. The vertical and horizontal adjustment settings are engraved on the timing screw, adjust
E. Horizontal adjustment: Adjust with a container in the pocket of the timing screw. Screw
F. Vertical height settings are graduated in millimeters (mm) as shown by the scale at
SPEEDGLIDER  ADVANCED OPERATOR MANUAL
screw aligns with the keyway at the drive motor shaft.
the timing screw accordingly.
Scaled
height
setting for
tim ing screw .
Tim ing scr ew w ith m anufactur er 's specifications m olded into the surface.
should make solid contact with container. There should be a 1/16 inch gap between the
container and the railing. Twist the locking lever counter-clockwise to open and free the
pedestal for movement. Forward and backward adjustment is achieved by turning the
knurled adjustment screw. Distance is scaled in millimeters (mm). After adjustments are
complete twist the locking lever clockwise to close to secure the pedestal.
each end. Vertical Adjustment: Left and Right Ends The timing screw is raised and
lowered using the two adjustment palm-screws. Unlock and twist clockwise to raise and
counter-clockwise to lower. Lock into position with dampener handle at each end as
shown
Twist to
raise
and
lower.
Left: Scale at left end. Right: Scale at right end (shown with timing screw removed). Inset: Close-up view of scale. Reading
Twist to raise
and lower.
here shows a setting of 74 mm.
50
CONTAINER CHANGE OVER
Scaled horizontal
center setting for
tim ing screw .
