AIR LOGIC POWER SYSTEMS (ALPS)

Hoisting and Transport of this Machine

The SpeedGlider machine must be hoisted in the manner shown by a fork-lift. Forks must be of sufficient length to
support the entire machine. Warning! This machine has a high center of gravity. Do not transport with forks
tilted forward! Forks must remain parallel with the floor. A potential injury hazard exists as this machine can
overturn easily if caution is not observed. Refer to section 2 of the service and maintenance manual for procedures
relating to the transit of this machine to a new location.
The SpeedGlider Linear Leak Tester should be mounted on firm and level floor space. This machine comes with
various height settings. Verify that contact is solid and the machine is level at all four corners. Adjust all four feet as
shown to level the machine. Use a carpenter's level to accomplish this.
Optional
Height
settings
GENERAL INFORMATION
Machine Weight:
1000 LBS.: Lift
from this side.
Adjustment
nut. Use a 1-
1/8" open-end
or box
wrench to
adjust. Adjust
lower hex nut
beneath to
tighten foot.
