AIR LOGIC POWER SYSTEMS (ALPS)
Load Recipe from Memory Card to HMI-continued
2. Do NOT select from the recipe name area at right.
5. With the selection made, select Step 1 (You will be prompted to select a source or cancel).
6. After the selection is made, press: Step 2 (save options to HMI and complete the transfer, right).
7. Re-open the control enclosure and remove the memory card. Secure the enclosure.
Step One
Step Two
Note: It is vitally important that both steps be followed in order
SPEEDGLIDER ADVANCED OPERATOR MANUAL
Select Recipe number
in left column only.
31
THE SETTINGS MENU
TM 2012-005 REV02 © 03/19/2013
