AIR LOGIC POWER SYSTEMS (ALPS)
THE SETTINGS MENU
Probe Take Off Introduction
The probe take off adjustment is a setup aid for centering the test probes on the container. This process is used
to fine tune the test probes or for a container change over where the timing screw is changed out to
accommodate a different size container.
Notice: The adjustment displays and procedure for aligning the test probes for a 3 or 4 heads SpeedGlider will be
different than a 2 head SpeedGlider.
3 and 4 head Adjustment Display
2 head Adjustment Display
SPEEDGLIDER ADVANCED OPERATOR MANUAL
23
TM 2012-005 REV02 © 03/19/2013
