10. Product Specifications

Size
Resolution
Pixel Pitch
Color Depth
LCD
Viewing Angle
Luminance of white
Contrast Ratio
Display Area
1 X HDMI
Input
1 X BNC
1 X HDMI
Output
1 X BNC
3G-SDI
HD-SDI
Input Signal
SD-SDI
HDMI
SMPTE-425M-A/B
SMPTE-274M
SDI Input Signal
Formats
SMPTE-296M
SMPTE-125M
ITU-R BT.656
Audio In
Audio Out
Power
Power Consumption (Approx.)
Tally Signal In/Out Level
Operating Temperature
Storage Temperature
Main Body Dimensions (mm/inch)
Box Dimensions (mm/inch)
Weight
Basic Accessories
Optional Accessories
* The specification above may be changed without notice.
* When using a DC Adapter other than the one supplied by the manufacturer, please be advised that
the adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
5.5"
1920×1080(16:9)
0.0213(W) x 0.0639(H) mm
16.7M (True)
H : 160 degrees / V : 160 degrees
500 cd/ m (Center)
2
1,000 : 1
122.7(H)x69.0(V) mm
HDMI V1.2 Input 1Ch
3G/HD/SD SDI Input 1Ch
HDMI-HDMI, SDI-HDMI (Conversion)
3G/HD/SD SDI Output 1Ch, HDMI-SDI (Converision)
2.970Gbps
1.485Gbps
270 Mbps
480i / 480p / 576i / 576p / 720p / 1080i / 1080p
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
720p (60/59.94/50)
480i (59.94)
576i (50)
SDI Embedded Audio (Group, Ch Selectable)
External Output Port (3.5m Phone Jack)
DC 6V 1.25A/34V 0.27A
TBD
DC5V ±2V
0℃ to 40℃ (32 ℉ to 104 ℉ )
-20℃ to 60℃ (-4 ℉ to 140 ℉ )
162.5 X 92 X 35.8 (6.4 X 3.62 X 1.41)
225 X 155 X 128 (8.85 X 6.10 X 5.03)
0.42Kg / 0.92 lbs
Acylic Filter, DC Power adapter, AC Power Cord, BNC Connector (Angle Type),
Camera Mount
Carrying Case, Sun-Hood, Tripod Ball Head, HDMI Bracket, Battery Bracket,
Battery Adapter, D-Tap cable
F-5A
