DEMO MANUAL DC2681A-A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 3 CIN3, CIN4
3 3 COUT1, COUT2, COUT4
4 2 COUT7, COUT8
5 1 C2
6 1 C3
7 1 C5
8 1 C8
9 1 C11
10 1 Q1
11 2 R3, R19
12 1 R4
13 1 R9
14 2 R14, R16
15 1 R15
16 1 R20
17 1 R25
18 1 R26
19 1 U1
Additional Demo Board Circuit Components
1 0 CIN2
2 0 CIN5, COUT3, COUT5, COUT6,
COUT9, COUT10
3 0 COUT11, COUT12
4 0 C4, C6, C7, C9
5 6 R1, R6, R13, R18, R21, R27
6 0 R8, R10, R11, R17, R22, R23,
R24, R28
Hardware: For Demo Board Only
1 18 E1-E18
2 1 JP1
3 1 JP2
4 2 J1,J3
5 2 J2,J4
6 4 J2,J4 (×2)
7 2 J2,J4
8 2 J2,J4
9 2 J5,J6
10 2 XJP1, XJP2
11 4 MTGS. at 4 CORNERS
6
PART DESCRIPTION
CAP ., ALUM., 150µF, 35V, 20%, HVH
CAP ., 22µF, X5R, 25V, 20%,1210
CAP ., 100µF, X5R, 6.3V, 20%, 1210
CAP ., POSCAP , 330µF, 2V, D2E
CAP ., 4.7µF, X5R, 10V, 10%, 0603
CAP ., 0.1µF, X7R, 16V, 10%, 0603
CAP ., 120pF, X7R, 50V,10%, 0603
CAP ., 1µF, X7R, 50V,10%, 0805
CAP ., 1µF, X7R, 50V,10%, 0603
XSTR., MOSFET, N-CH, 40V, TO-252
RES., 10k, 1/10W, 1%, 0603
RES., 100k, 1/10W, 1%, 0603
RES., 47.5k, 1/10W, 1%, 0603
RES., 10Ω, 1/10W, 5%, 0603
RES., 90.9k, 1/10W, 1%, 0603
RES., SENSE, 0.01Ω, 1/2W, 1%, 2010
RES., 2.2Ω, 1/10W, 5%, 0603
RES., 50k, 1/10W, 1%, 0603
IC, LTM4645EY#PBF BGA77-15×9-5.01
CAP ., OPTION, 1206
CAP ., OPTION, 1210
CAP ., OPTION, D3L
CAP ., OPTION, 0603
RES., 0Ω, 1/10W, 0603
RES., OPTION, 0603
TESTPOINT, TURRET, .062"
CONN., HEADER, 2×4, 2mm
CONN., HEADER, 1×3, 2mm
CONN., BANANA JACK
STUD, TESTPIN
NUT, BRASS 10-32
RING, LUG #10
WASHER, TIN PLATED BRASS
CONN, BNC, 5 PINS
SHUNT, 2mm
STAND-OFF , NYLON, SNAP-ON, 0.50" TALL
MANUFACTURER/PART NUMBER
SUN ELECTRONIC INDUSTRIES CORP ., 35HVH150MT
MURATA, GRM32ER61E226ME15L
MURATA,GRM32ER60J107ME20L
PANASONIC, 2TPF330M6
AVX, 0603ZD475KAT2A
AVX, 0603YC104KAT2A
YAGEO, CC0603KRX7R9BB121
MURATA, GRM21BR71H105KA12L
TAIYO YUDEN, UMK107AB7105KA-T
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060347K5FKEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW060390K9FKEA
VISHAY, WSL2010R0100FEA
VISHAY, CRCW06032R2JNEA
VISHAY, CRCW060350K0FKEA
LINEAR TECH., LTM4645EY#PBF
MURATA, GRM31CR6YA106KA12L
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
OPT
MILL-MAX, 2308-2-00-80-00-00-07-0
SULLINS, NRPN042PAEN-RC
SULLINS, NRPN031PAEN-RC
KEYSTONE, 575-4
PEM, KFH-032-10
ANY, #10-32M/S BR PL
KEYSTONE, 8205
ANY, #10 EXT BZ TN
CONNEX, 112404
SAMTEC, 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
dc2681aaf
