Appendix D Mechanical Dimensions; Table 43. Mechanical Dimensions; Figure 53. Mechanical Dimensions - STMicroelectronics STM32G081B-EVAL User Manual

UM2403
Appendix D
Symbol
A
A1
a
B
D
d
E
Mechanical dimensions

Figure 53. Mechanical dimensions

Table 43. Mechanical dimensions

Size (mm)
68.58 e
61.97 H
2.54 Lx
36 Ly
3.5 Mx
3.2 My
47 P1
UM2403 Rev 2
Symbol Size (mm)
77.44
11
5.715
5.715
19.08
23.81
65.78
Mechanical dimensions
Symbol Size (mm)
P2 111.76
P3 10.41
Q1 24.12
Q2 17.70
Q3 16
X 114.3
Y 172.72
