Conventions

4 Conventions
Table 3 provides the conventions used for the ON and OFF settings in the present
document.
5

Delivery recommendations

Some verifications are needed before using the board for the first time, to make sure that no
damage occurred during shipment and that no components are unplugged or lost.
When the board is extracted from its plastic bag, check that no component remains in the
bag. The main component to verify is microSD card which may have been ejected from the
connector CN8 (right side of the board).
Caution: There is an explosion risk if the battery is replaced by an incorrect one. Make sure to
dispose of used batteries according to the instructions.
12/79

Table 3. ON/OFF convention

Convention
Jumper JPx ON
Jumper JPx OFF
Jumper JPx [1-2]
Solder bridge SBx ON
Solder bridge SBx OFF
Resistor Rx ON
Resistor Rx OFF
UM2403 Rev 2
Definition
Jumper fitted
Jumper not fitted
Jumper should be fitted between Pin 1 and Pin 2
SBx connections closed by 0 Ω resistor
SBx connections left open
Resistor soldered
Resistor not soldered
