UM2403
Pin number
4
5
7.1.9
Standard SWD connector CN12
Pin number
1
3
5
7
9
11
13
15
17
19
Table 29. RS232 & RS485 connector CN11 (continued)
Description
RS485_A
GND
Figure 15. Standard SWD debugging connector CN12 (top view)
Table 30. Standard SWD debugging connector CN12
Description
VDD
NC
NC
SWDAT(PA13)
SWCLK(PA14)
10K pull-down
NC
RESET#
10K pull-down
10K pull-down
UM2403 Rev 2
Pin
number
9
RS485_B
-
-
Pin
number
2
VDD
4
GND
6
GND
8
GND
10
GND
12
GND
14
GND
16
GND
18
GND
20
GND
Connectors
Description
Description
39/79
