STMicroelectronics STM32G081B-EVAL User Manual page 67

Figure 47. STM32G081B-EVAL UCPD daughterboard Type-C source con
TYPE-C DRP port (Port1)
CN7
5
PAD
6
PAD
Differential pairs 90ohm
A1
GND1
C1_TX1+ A2
C1_TX1+ TX1+
C1_TX1- A3
C1_TX1- TX1-
A4
VBUS1
A5
CC1
A6
D+1
A7
D-1
A8
SBU1
A9
VBUS2
C1_RX2- A10
C1_RX2- RX2-
C1_RX2+ A11
C1_RX2+ RX2+
A12
GND2
1
SHELL
2
SHELL
317JD24BZTF3K3C3
C1_D+
C1_D+
C1_D-
C1_D-
VBUS1
C16
1uF[N/A]
VBUS1 3A
C112
B14
GND
B13
GND
Differential pairs 90ohm 390pF[N/A]
B12
GND4
B11 C1_RX1+
RX1+ C1_RX1+
B10 C1_RX1-
RX1- C1_RX1-
B9
VBUS4
B8
SBU2
B7 C113
D-2
B6
D+2
B5
CC2
390pF[N/A]
B4
VBUS3
B3 C1_TX2-
TX2- C1_TX2-
B2 C1_TX2+
TX2+ C1_TX2+
B1
GND3
3
SHELL
4
SHELL
VBUS1
VBUS1
D6
SB25
ESDA25P35-1U1M
R126
1K/0.5W
C1_CC1 SB56 1_CC1
C1_CC2 SB57 1_CC2
C1_SBU1 SB58 1_SBU1
C1_SBU2 SB53 1_SBU2
D5
ESDA25SC6[N/A]
SB27
SB28
U17
SB54 7 12
RPD_G1 CC1
SB55 6 11
RPD_G2 CC2
15
SBU1
C1_CC1 4 14
C_CC1 SBU2
C1_CC2 5
C_CC2
C1_SBU1 1
C_SBU1
C1_SBU2 2
C_SBU2
3
VBIAS
C1_D- SB70 20
D1
C1_D+ SB71 19
D2
17 10
D3 VPWR
16
D4
18
GND
8
GND
13 9
GND /FLT
21
PAD
TPD8S300RUKR
U19
C1_TX1+ 1 10
C1_TX1- 2 9
3 8
C1_RX1+ 4 7
C1_RX1- 5 6
HSP051-4M10
Title: TYPEC_SOURCE_CON
Project: STM32G081B-EVAL USB-C daughter board
Variant: Variant name is not interpreted until output
Revision: C 02 -
Size: A4 Date:
SB21 1_CC1
1_CC1
SB22 1_CC2
1_CC2
1_SBU1
1_SBU1
1_SBU2
1_SBU2
C54 100nF
VDD
R114 C51
100K
1uF_X5R_0603
U20
C1_RX2- 1 10
C1_RX2+ 2 9
3 8
C1_TX2- 4 7
C1_TX2+ 5 6
HSP051-4M10
Reference: MB1352
3-Aug-18 Sheet: 5 of 10
