UM2403
7.3.4

USB3.1 Gen1 Type B connector CN4

Pin number
1
2
3
4
-
7.3.5

USB Type-C connector PORT2 CN5

Pin number
A1
A2
A3
A4
A5
A6
A7

Figure 25. USB3.1 Gen1 Type B connector CN4 (front view)

Table 38. USB3.1 Gen1 Type B connector CN4

Description
VBUS (power)
D-
D+
GND
-

Figure 26. USB Type-C connector PORT2 CN5 (front view)

Table 39. USB Type-C connector PORT2 CN5

Description
GND
TX1+
TX1-
VBUS
CC1 (PD0)
D+
D-
UM2403 Rev 2
Pin number Description
5 SSTX-
6 SSTX+
7 GND_DRAIN
8 SSRX-
9 SSRX+
Pin number
B1 GND
B2 TX2+
B3 TX2-
B4 VBUS
B5 CC2 (PD2)
B6 D+
B7 D-
Connectors
Description
45/79
