UM2403
7.1.14

Analog input connector CN17

Pin number
1
7.2

Connectors on legacy peripheral daughterboard

7.2.1

HDMI sink connector CN1

Pin number
1,3,4,6,7,9,10,12
13
14
15

Figure 18. Analog input-output connector CN17 (top view)

Table 32. Analog input-output connector CN17

Description
Analog input-output PB2

Figure 19. HDMI sink connector CN1 (front view)

Table 33. HDMI sink connector CN1

Description
TMDS differential signal pair
connected to CN3
CEC (PB10)
NC
I2C2_SCL (PB13)
Pin
number
2
Pin number
16
2,5,8,11,17
18
19
UM2403 Rev 2
Description
GND
Description
I2C2_SDA (PB14)
GND
HDMI_5V_Sink
HPD (PD2 through transistor)
Connectors
41/79
