Supplementary system components
6.2 Fan/battery module
6.2.3
Replace battery in the fan/battery module
Overview
The procedure for replacing the double fan/battery module's battery is described below.
Procedure
Proceed as follows to replace the battery:
1. Press the latch. This detaches the module from its front latching device.
2. Tilt the double fan/battery module forwards at an angle and pull out the plastic lug from
3. Remove the battery using a screwdriver (at the side) and disconnect the battery from the
96
Figure 6-3
Unlatch the double fan/battery module
the Control Unit cutout.
module by unplugging the connector.
SIMOTION D4x5-2
Manual, 02/2012
