2.2.6 Connecting the Power Cord and Ground Wires
Connect the power cord and ground wires to the universal receptacle. See
11.
LIVE
SIDE PANEL
KNOCK OUT
EARTH
GROUND
Operations Guide
Figure 2-10. Wiring the Universal Receptacle
L
E
931240M
Installing the SIP Loudspeaker Amplifier (AC-Powered)
SIP Loudspeaker Amplifier (AC-Powered) Setup
Figure 2-10
N
and
Figure 2-
NEUTRAL
SIDE PANEL
KNOCK OUT
EARTH
GROUND
CyberData Corporation
17
