2.2.4 Installing the SIP Loudspeaker Amplifier (AC-Powered)
Install the SIP Loudspeaker Amplifier (AC-Powered) as shown in
Figure 2-8. Installing the SIP Loudspeaker Amplifier (AC-Powered)
Operations Guide
Installing the SIP Loudspeaker Amplifier (AC-Powered)
Paging Amplifier
Mounting Screw
Paging Amplifier
931240M
SIP Loudspeaker Amplifier (AC-Powered) Setup
Figure
2-8.
Network Cable
to Network Port
CyberData Corporation
15
Network Cable
through Cable Gland
