SmartRunner Detector
Vision Configurator Software
6.6
Common
Common Tab
The general tab for setting the sensor configuration.
"Communication" Tab
Figure 6.13
RS485 head address: Address in the RS485 bus. The address is sent with every RS-
485 command (see chapter on RS-485 communication) and is used for identification
purposes if multiple sensors are installed in the bus.
Baudrate: Baud rate with which the sensor communicates via RS-485. When you change
the baud rate, the baud rate of the Vision Configurator is also automatically changed, so
that communication still remains possible.
Bus termination: Activates the integrated terminating resistor to terminate the RS-485
bus on the sensor
"Trigger" Tab
Figure 6.14
Autotrigger: Switches the autotrigger function on or off
Common tab: Communication
Common tab: Trigger
35
