SmartRunner Detector
Vision Configurator Software
"Lighting" Tab
Figure 6.15
Exposure time: Setting for the manual exposure time. If the "Use manual exposure time"
checkbox is deactivated, this value has no significance.
"Use manual exposure time" checkbox: The manually set exposure time is used when
this checkbox is activated. If this box is not checked, the exposure time during the teach-in
process is controlled automatically.
Auto exposure time: The current exposure time is output in this field.
"Refresh auto exposure time" button: Pressing this button updates the "Auto exposure
time" field.
"Mode" Tab
Figure 6.16
Presentation mode: Switches presentation mode on or off
36
Common tab: Lighting
Common tab: Mode
