6.3
Toolbar
Using the toolbar, various functions can be called up directly.
6.4
Image Display
Image View
Displays image data. Selected via the "Image View" button. "Get image" loads the last captured
image on the PC and displays it in the window. To capture a new image, "Trigger" must have
been clicked.
Figure 6.8
32
The connection between the PC and the sensor is disconnected.
Opens a saved setting.
Saves the settings made.
Settings are read out from the sensor.
All settings made are saved on the sensor.
Image View
