Table 6.3
Note!
Firmware Update
Once you have upgraded the firmware and Update complete is displayed, restart the sensor.
6.1.4

Image Menu

Figure 6.5
Open image folder
Save image
Copy image to clipboard Loads an image file to the clipboard.
Show graphic
Table 6.4
6.1.5

Administration Menu

Figure 6.6
If the sensor is connected to the PC via Ethernet, this command
enables you to change some of the connection settings on the
sensor. Once you have changed the settings, the connection
between Vision Configurator and the sensor is automatically
disconnected. If required, change the network address to the
newly allocated IP and reconnect Vision Configurator to the
sensor. Press the Connect button to open the Login screen
again.
Performs firmware updates. This command should be used by
experienced users only.
Synchronization with the sensor
Sensor Menu
Image Menu
Opens the folder in which images are currently saved.
Saves the image currently displayed on the PC.
Turns display data sent from the sensor on and off in the image.
