Detection Range

Y
max
Field of view
1
Detection range
2
Note the detection range of the SmartRunner detector when planning your plant. The following
table contains information on the detection range and the resolution.
min
max
Note!
The smallest possible object size increases linearly with the distance Y to the sensor.
18
Y
min
X
min
2
1
Detection range X Distance Y to the sensor
45 mm 55 mm
350 mm 700 mm
X
max
Minimum object size
0.25 mm
1.0 mm
