SmartRunner Detector
Commissioning
Note!
All values are transferred in little-endian format. This saves the least significant byte at the
lowest address, i.e. the least significant component is specified first.
Example
ROI for evaluation: Sets the ROI to ±50 mm in the X direction and to between +100 mm and
+200 mm in the Z direction:
0x 10 C8 CE FF FF FF 32 00 00 00 64 00 00 00 C8 00 00 00 77
0x10 = data length
0xC8 = Index
0xCEFFFFFF = X
0x32000000 = X
0x64000000 = Z
0xC8000000 = Z
Response telegram:
13.02.2017 11:39:17.68 [TX] -80 C8 48
13.02.2017 11:39:17.69 [RX] -90 C8 CE FF FF FF 32 00 00 00 64 00 00 00 C8 00
00 00 F7
-50 mm (little-endian, two's complement)
min
+50 mm (little-endian, two's complement)
min
+100 mm (little-endian, two's complement)
min
+200 mm (little-endian, two's complement)
min
