PCAN-Router Pro – User Manual
5.5

Status LEDs

Applies to the standard firmware except for the "Power" LED.
LED State
Power Off
Green
μC Status Green
(1 Hz)
Green
(2 Hz)
Green
with short light phase
(2 Hz)
Red
CF Card Orange
LED 1 Configurable (green)
LED 3
LED 5
LED 7
LED 2 Configurable (red)
LED 4
LED 6
LED 8
Meaning
If a supply voltage is applied, the PCAN-Router
Pro is in power-down mode and must be turned
on by a wake-up signal. See following section
5.7.
static A supply voltage exists and the PCAN-Router
Pro is turned on.
slow blinking Normal operation with the configuration which
is allocated to the currently specified Router ID.
quick blinking No or no valid configuration is available for the
currently specified Router ID.
Changing the Router ID:
section 3.3 on page 16
Transferring a configuration to the PCAN-
Router Pro:
see program help of the PPCAN-Editor
quick blinking Configuration transfer to/from the PCAN-Router
Pro via CAN (ID 7E7h)
Reset
Due to the shortness of the reset signal, this
status is barely viewable.
blinking Write access onto the CompactFlash card
Freely configurable, access via I/O functions
00h (Dout Level) > LED CAN
30
