PCAN-Router Pro – User Manual
The CF card is properly inserted if it flushes with the rear
panel.
Note: When you want to insert or eject a CompactFlash card,
the PCAN-Router Pro must be turned off (no power supply or
power-down mode, Power LED off). Else the card is not
detected or data gets lost.
6.2 Preparing a Configuration for
Recording
In the configuration program PPCAN-Editor the recording of the
CAN traffic is set up in the module-specific configuration ( ) on the
Default values for data objects tab.
The entries for the recording
are created in the module-specific configuration.
35
