PCAN-Router Pro FD – User Manual
Pin Name
4 Digital In/Out 4
5 GND
6 Analog In 1
2.4

Status LEDs

When a power supply is applied, the power LED lights up green. All
other LEDs can be programmed with their own firmware. More
details can be found in the supplied C code examples.
2.5

USB Connection

The internal memory and the external SD card of the PCAN-Router
Pro FD can be accessed via a USB connection with a PC. The
operating system on the PC integrates the memory card into the file
management, for example as a mass storage device under
Windows. Only FAT 32 is supported as the file system for the
internal and external storage medium. Via the USB connection, for
example, stored traces files can be accessed.
Note: Access to the USB connection via the CPU is not
possible.
2.6

SD Card Slot

Optionally, a memory card can be inserted into the SD card slot.
The SD card can be accessed via the USB connection.
Function
Digital input and output 4 (low-side)
Ground
Analog input 1
11
