PCAN-Router Pro – User Manual
11. Click the (Program) button in order to start uploading the
new firmware to the PCAN-Router Pro.
Observe the status indication at the bottom of the window.
The process was successful if the last message to appear is
"Flashing of module(s) finished!".
12. BL-SW: Click the
The "μC Status" is blinking.
13. BL-HW: Disconnect the power supply from the PCAN-
Router Pro.
14. BL-HW: Turn the "Router ID" rotary switch back to the
previously noted setting.
15. BL-HW: Put the cover back onto the casing (taking care of
LED light guides) and fasten it with the four screws.
You can now use the PCAN-Router Pro with the new firmware.
After an update of the standard firmware, the "μC Status" LED
blinks with increased frequency (2 Hz) indicating that no configure-
tion is available. Re-transfer your configuration(s) to the PCAN-
Router Pro with the PPCAN-Editor.
(Reset module) button.
