PCAN-Router Pro – User Manual
Do the following to replace a transceiver module:
1. Remove the retaining screw from the transceiver module to
be replaced. Take care of the spacer and the nut that are
possibly get loose.
2. Pull off the transceiver module upwards from the main
board.
3. Plug the alternative transceiver module onto the socket.
Make sure that the hole in the transceiver module is aligned
to the corresponding hole in the main board.
4. Secure the transceiver module with the screw, the spacer,
and the nut.
At restart, the PCAN-Router Pro automatically detects the type of
the inserted CAN transceiver module and adjusts the according
default bit rate for the CAN channel (see table above). The bit rate
can be changed by a configuration.
Note: Having customized equipment, if there is no CAN
transceiver module with wake-up function, the PCAN-Router
Pro must be switched on with an external wake-up signal (see
section 5.7.3 on page 32).
