PCAN-Router Pro – User Manual
Module name
CAN-HS
HSGE2
CAN-HS-1041
(standard equipment)
CAN-LS
CAN-LS-SW
The default bit rate is enabled if the current configuration in the
PCAN-Router Pro does not provide another bit rate. In a configu-
ration the bit rate can be set independently for each CAN channel.
This is done with the I/O function
Tip: If the communication with the PCAN-Router Pro is preven-
ted because you do not know the bit rates used by a configu-
ration, you can set the Router ID to a position without configu-
ration (see section 3.3 on page 16). Then the default bit rate is
enabled.
5.3

Shipping Configuration

Applies to the standard firmware.
The PCAN-Router Pro contains an example configuration at
delivery. You can change its elements (e.g. the CAN IDs) or use
them as basis for own configurations.
For editing the shipping configuration in the PPCAN-Editor it is
contained on the provided DVD as file ShippingConfig.ppproj.
This configuration has following properties:
All incoming messages from the four CAN channels are written
to an inserted CompactFlash card.
No forwarding is done between the four CAN channels.
Transmission standard
High-speed CAN ISO 11898-2
High-speed CAN ISO 11898-2
High-speed CAN ISO 11898-2
Low-speed CAN ISO 11898-3
Single-wire CAN SAE J2411
70h (Special Out) > CAN Bitrate
24
Default bit rate
500 kbit/s
500 kbit/s
500 kbit/s
125 kbit/s
33.3 kbit/s
.
