PCAN-Router Pro – User Manual
2. Restart the PCAN-Router Pro by briefly cutting off the power
supply.
After the restart the changed Router ID will be active. Before
the restart changes made at the rotary switch will have no
influence on operation.
During operation with a configuration the LED "μC Status" blinks
green every second. If a configuration for the set Router ID does not
exist, the LED blinks twice as fast.
3.4 Enabling the 5-Volt Supply for
External Devices
A 5-Volt supply can optionally be routed to pin 1 of a D-Sub
connector (independently for each connector) by setting solder
jumpers on the circuit board of the PCAN-Router Pro. Thus devices
with low power consumption (e.g. bus converters) can be directly
supplied via the D-Sub connector. The current output is limited to
100 mA for each connector.
Proceed as follows to activate the 5-Volt supply:
Set the solder jumper(s) on the circuit board of the PCAN-Router
Pro according to the desired function. During this procedure take
especially care not to produce unwanted short circuits on the board.
The following figure shows the positions of the solder fields on the
circuit board. The table below contains the possible settings.
17
