Position Length
(byte:bit) (bits)
0:5 1
0:6 1
0:7 1
1:0 1
1:1 1
1:2 1
CAN property
ID
Data length
Transmit cycle
time
RTR
Format
Data
Position Length
(byte:bit) (bits)
0:0 32
4:0 32
Name of data
variable
FileNotFound
FileOpenError
FileSeekError
FileStartError
EndOfFileError
RunAllocationErr
or
Message GetTraceInfo_R
7F1h
8 bytes
none (0 ms)
yes
Intel (Little Endian)
See following table
Name of data variable Description
CFTraceFileMsgFree
CFTraceQueueOverru
ns
Description
File trace.btr does not exist
File trace.btr cannot be opened
Start of file trace.btr cannot be found
First sector of file trace.btr cannot be
determined
Trace file is completely filled with CAN
messages (linear record mode)
Maximum number of records is reached
Number of CAN messages still fitting
into the trace file
Number of CAN message not being
processed by the CF card queue due
to overload
